Aaspa Slipform Kerbing Machine 1000 a most versatile machine for making type of kerb for highway, footpath (122 CMS wide 478″) & small box gutters etc.
The machine is basically self propelled drive by a compact water cooled diesel engine having a rubber padded crawler track driven by a powerful hydraulic motor with fully proportional automatic electronics controls. The machine is supplied with quick change mould mechanism .
Mould can be change within 30 minutes for paving a new mould profile. The machine is equipped with world class fully variable vibrators to ensure concrete flow.

Aspa AKM 1000 is a low profile machine and can be fed directly by tack mixer. Conveyors or augers are necessary. The operator is well positioned to see all facts of the operation. Adjustment to speed and vibrators are quickly verified because the formed concrete is right beside the operator. Machine can lay on wet mix and DBM layers as well as reinforcement and gutter section.

Machine perform with low fuel consumption and fast working speed as well as travelling speed.

Control Panel

World Class Vibrators
Moba Sensing System
Quick Change Mould Design
Yanmar TNV Series Diesel Engine
Fully Hydrostatic Drive

World Class Components

YANMAR Diesel Power Quiet & Reliable
REXROTH Hydraulic Pumps Top Quality
WYCO Vibrators Best Performance
MOBA Sensing System Used by Pavers World Wide
FAIRFIED "Torque Hub" A Field Leader
PARKER Drive Motor Accepted World Wide
FILREC Filtration System Best Quality

Technical Specification

Model AKM-1000
Kerb Laying Capacity Minimum : 750 mm (W) X 575 mm (H)*
Engine Yanmar make water cooled diesel engine generating 36 HP (27.2 kw)
Vibrators Wyco USA
Hopper Capacity 0.5 cubic meters
Electrical System 12 V DC, Battery : 75 AH
Steering Type Power Steering
Sensing Moba control system
Breaking System Through planetary gear box with integrated hydro motor & brake.
Cylinders Lift front and steer 12" x 3"
Capacities Fuel 46 Ltr./ Hydraulic 120 Ltr.
Wheels Heavy duty solid rubber tyres on heavy duty rims. Cast steel hubs and heavy duty stub axles on rocker beam for more consistent grade control
Speed Operating speed -2/3 mts/min. & Travel speed 15 mts/min.
Shipping  Dimension ( LxWxH) 3870 mm (12′ 8") x 2305 mm ( 7’7") x 1440 mm ( 4′ 9")
Shipping Weight 3950 kg.
