Vertical Storage Silo AS-300
AASPA 300 tones capacity, bolted type cement silo AS-300 is preferred especially in high capacity concrete batching plants and also in projects that cement stocking has a critical role.
AASPA AS-300 cement silo is equipped with maintenance platform between the legs, cement filling pipe, inner and outer manholes, safety guards, roof flanges for air filter and pressure safety valve, a roof gate for inner manhole and also a cone flange for butter fly valve.
AASPA AS-300 cement silo is supplied together with all necessary silo equipment such as cement screw conveyor with the desired diameter & length, air filter, pressure safety valve, top & bottom level indicators, air fluidization nozzles, pulse valve and cone butter fly valve for manual cement discharging.
Parts of AS-300 bolted type cement silo are manufactured by sensitive laser cutting and drilling methods. In the jobsite, parts of cement silos can be assembled easily and sensitively.
AS-500 Vertical Storage Silo Delivers High-Capacity Bulk Storage While Reducing Space Requirements and Maintenance Costs.
Specification
| Silo Capacity | 300 TONS, 230 m3 ( cement density as 1,3 ton/m3 ) |
| Silo Height | 18450 mn |
| Silo Diameter | Ø 5140 mm |
| Quantity Of Silo Legs | 6 |
| Silo Output Diameter | Ø 300 mm |
| Number Of Components | 191 |
| Silo Weight | 22000 Kg |
| Material Of Silo Legs | Ø273 x 10 mm, STEEL PIPE |
| Supports Of Silo Leg | NPL 80 mm CORNER IRON |
| Sheet Metals Of Silo Leg | 20 mm SHEET METAL |
| Conical Part Support Material | 200 mm STEEL C CHANNEL |
| Conical Part Material | ST – 37 ,8 mm SHEET METAL |
| Silo Body Material | ST – 37, 8-6-5 mm SHEET METAL |
| Silo Top Cover Material | ST – 37 , 5 mm SHEET METAL |
| Charging Pipe | 4″ STEEL PIPE UP TO SILO LEG |
| Inner Manhole Is Present | |
| Outer Man Hole Is Present | |
| Silo Roof Includes Handrails | |
| Maintenance Platform Is Present | |
| Structural Analysis Is Made For The Silos And Manufacturing Process Depends On Approved Projects. | |
| painting : 1 layer of anticorrosive paint, 2 layer of final coat epoxy paint, total paint thickness: 140 microns. | |
