Bitumen Emulsion Spareyer
TANK
The tank is fabricated by a 5mm MS sheet and is coated with 40 mm glass wool. The is done to Prevent heat loss. The outer covering is galvanized tank is better as it has long life due to its anti -Corrosion properties Tank is 6 inches. Manhole for maintenance or to all bitumen tank is if 500mm x 600mm . A manual Temperature gauge is provided for temperature dishplay up to 300 Degrees Celsius.
ENGINE
Single stage air cooled diesel engineer of 6.5 HP at 1500 RPM ,engine powers bitumen pump and air compressor.Fule consumption is 0.7-1 Liters per hour.
Sub Heading
Sub Heading
Sub Heading
Sub Heading
Sub Heading
Sub Heading
Sub Heading
Sub Heading
Latest Searches Of Bitumen Emulsion
- Best Bitumen Emulsion Sprayer With Compressor
- Top Tractor Mounted Bitumen Sprayer
- Bitumen emulsion BS-200 Price
- Best bitumen hand sprayer for sale
- bitumen sprayer price
- Top Bitumen Emulsion Sprayer With Dust Remover
- Best Bitumen Emulsion Sprayer Equipment
- Best Bitumen emulsion Sprayer BS-1000
- Semi Automatic Bitumen Sprayer Price
- Top emulsion sprayer equipment
| Bitumen Tank | Capacity: 1000 to 8000 Liters Shape: U Shape Insulation: 40 mm thick with glass wool Temp. Gauge: 0–300°C Main Hole: 450 mm in diameter Mounting: Self chassis mounted on wheels |
| Manual Handspraying | Pipe Length: 5 meters Type of Pipe: S.S. corrugated hose pipe Spraying Pressure: 0–3 kg/cm² |
| Bitumen Pump | 1.5” × 1.5” size positive displacement gear pump, output of 200–300 liters/min |
| Air Compressor | Standing make Air compressor |
| Burner | Fuel consumption 7/8 liters/hour |
| Engine Fuel Tank | Capacity 5 liters |
| Burner Fuel Tank | Capacity 20 liters |
| Engine | Standard make air-cooled diesel engine powered by 6/10 HP |
| Road Air Cleaning | Standing make twin lob Air compressor |
Bitumen Pump And Air Compressor
Both bitumen pumps and air compressor are engine dilven. Bitumen pump is connected to theengine by a manual clutch.just on gaging the clutch will activate the pump. Bitumen pump gertype 200 to 300 Liters per minute. 2 HP Single piston air compressor is provided.
